Description
Upper equipment configuration: The total tank volume is about 33 cubic metres, with a clean water tank of about 10 cubic metres and the rest as a sewage tank. It has a reinforced frame, a self-unloading design, two interconnected compartments, made of 8mm carbon steel. For the sewage suction part, the auxiliary engine is a Weichai 420 horsepower with an SK-258 water circulation pump, 8-metre sewage suction pipe, widened platform with guardrails on both sides of the tank, an 800mm hydraulic sewage outlet at the rear, a 150 sewage ball valve, and a 100 sewage ball valve, 100 internal suction ball valve, 150 illicit discharge ball valve, arrow lights on both rear sides, equipped with a 350 flow float, 100-metre custom wear-resistant high-pressure hose with 25mm inner diameter, with a reel, reel can rotate hydraulically left and right, and a 10kg gun nozzle.
