Maximum working height: 20 meters
Maximum lifting capacity: 5000 kg
Platform rated load: 200 kg
Swivel structure: 360-degree arbitrary rotation
Platform swivel range: ±180°
Power pump: Single pump
Operation mode: Mid-operation, remote control
Platform dimensions: 1600 mm * 700 mm * 1000 mm
The guardrail height is 500mm. The boom: a 6-section internal cable boom with 5 sections synchronously telescoping. The steel wire rope has a backup cable for the boom, ensuring a smooth descent even if the main cable breaks
Operating System: A renowned domestic electronic control system, equipped with a wireless remote controller and three-party operation. Hydraulic System: Electro-hydraulic proportional valves with stepless speed adjustment, featuring an emergency power source. Hydraulic Support Legs: H-type support legs with four telescopic legs, individually adjustable. Safety Devices: Interlocking for upper and lower operations, soft leg protection (optional), and bidirectional hydraulic balance valves
